Making JSON-LD visible — the schema graph visualizer I wish Schema App didn't charge for

Part of the AEO / GEO / AI-search audit tool stack. See the pillar post for the full catalog of sibling audits and where this one fits in the lineup.

If your page has a Person schema nested inside an Article schema, pointing at a Review with its own itemReviewed link, that's a four-node graph. You can't see it in raw JSON unless you've mapped graphs in your head for a living. Most people can't.

The Schema Graph Visualizer draws it.

What the tool does

1. Fetches the URL
2. Parses every <script type="application/ld+json"> block
3. Recursively walks each object, assigns @id to anonymous nodes, tracks edges (which property of which node points to which other node)
4. Renders the flattened graph as SVG — concentric rings, top-tier types at center (Organization, WebSite), deeper types in outer rings
5. Color-codes nodes by @type — Organization green, Article amber, Person purple, Product pink, FAQ teal, etc.
6. Labels each edge with the property name ("author", "publisher", "mainEntityOfPage", "reviewedProduct")
7. Reports: disconnected nodes (orphans in the graph), blocks missing @context, weak connectivity (too many anonymous nodes)

Why the graph view catches issues text doesn't

Three common schema problems that are invisible in raw JSON but obvious in the graph:

1. Orphan nodes. You emitted a Person block with name + jobTitle + sameAs, but nothing on the page references the Person via @id. The Person floats alone. Google doesn't connect it to your Article authorship. Graph view: Person is a red disconnected circle. Text view: looks fine.

2. @context scatter. Some blocks declare @context: "https://schema.org", others are inside a @graph that declares context once, others don't declare at all. The last category is technically broken — Google may not parse types correctly. Graph view: flags block-level missing context. Text view: you'd have to check each block individually.

3. Weak connectivity. If half your nodes are anonymous (no @id), the graph has no way to reference them from other blocks. They exist but can't be linked. Graph view: shows the anonymous node count and recommends adding @id everywhere. Text view: looks normal.

How it flattens

The flattener walks each block recursively:

• Object with @id → use it as the node ID
• Object without @id → generate a stable anonymous ID (_anon:N:type)
• Array inside an object → visit each item with the array key as edge label
• Scalar value → skip (it's data on the parent node, not a child)

Edges capture the parent→child path, with the key name as the edge label. This produces a clean DAG in 99% of real-world JSON-LD.

How the SVG layout works

I don't use a full force-directed graph library (would add 60-100 KB). Instead, a ring-based layout:

• Center ring (0-1 nodes): Top-tier types — Organization, WebSite
• Inner ring (3-4 nodes): Page-level types — WebPage, Article
• Middle ring (8-10 nodes): Content types — BreadcrumbList, FAQPage, Product, Person
• Outer ring (everything else): Leaf content — ListItem, Question, Answer, Offer

This gives a clean, readable layout even for dense schema pages. Hover a circle, the browser's native <title> tooltip shows the full @id and @type.

How to use it

1. Go to /tools/schema-graph-visualizer/
2. Paste your URL
3. Click Run
4. Inspect the graph. Hover any circle for node details. Scroll for the type distribution table + raw parsed blocks.

Typical runtime: ~2-4 seconds per page.

What it pairs with

• Schema JSON-LD Graph Linter — the non-visual linter. Reports the same issues as text, for scripting / CI.
• Rich Results Eligibility Audit — per-type Google eligibility check.
• Schema Validator — fires schema through schema.org spec validation.
• LLM Answer Citation Tracker — paired release, checks if AI engines cite you.

The limits

• Static HTML only. If your JSON-LD is injected post-hydration (React / Vue / Svelte with no SSR), the tool can't see it. Use the Prerender vs Hydration Parity audit to fix that separately.
• No spec validation. The tool shows structure, not whether each @type has the right required fields. For that, use the Rich Results Eligibility Audit.
• No external-link resolution. If your schema references an external @id (say, a Wikidata Q-number), the tool shows the reference but doesn't follow it.

Related reading

• LLM Answer Citation Tracker — paired tool
• Scheduled Monitor — longer-term context
• Mega SEO Analyzer v2
